PFP-7 Industrial Flame Photometer

Designed for industrial analysis
Supplied with Na, K, Li, Ba and Ca filters
Low temperature, single channel
Flame failure safety system
Operates with propane, butane, natural gas or LPG

The PFP7 is a low temperature, single channel flame photometer that is designed for the routine determination of sodium, potassium, calcium, barium and lithium concentrations. The flame failure safety system makes these products ideal for use in industrial and educational environments. The use of fine and coarse sensitivity controls allows for accurate measurements each and every time.

DOWNLOAD PFP-7 Brochure PDF

Specifications:

Parameter:	PFP-7
Range:	0 to 199.9ppm
Limits of detection Na:	0.2ppm
K	0.2ppm
Li	0.25ppm
Ca	15ppm
Ba	30ppm
Reproducibility:	<1% coefficient of variation for 20 consecutive samples using 10ppm Na set to read 50
Linearity:	< 2% error when 3ppm Na/K and 5ppm Li are set to read 100
Stability:	< 2% drift over 5min when continuously aspirating 10ppm sample set to 50.0. Specificity Interference from Na/K and Li equal in concentration to test element will be <0.5%
Recorder output:	Nominal 1.00V for a reading of 100.0
Electrical supply:	90-125V or 190-250V @50/60Hz
Air supply:	Moisture and oil free, 6 litre/min @ 14psi
Fuel:	Propane, butane, natural gas or LPG
Size (w x d x h):	420 x 360 x 300mm
Weight:	8kg

Ordering Information:

Part Code:	500-701
Description:	PFP7 industrial flame photometer supplied with Na, K, Ba, Ca and Li filters, connecting hoses and clips, compressor plug and drain trap (230V/50Hz)

Regulator/Pressure Gauge Assembly
